This tape utilizes a specialized 0.130mm woven glass fiber cloth backing coated with a premium pressure-sensitive silicone adhesive, resulting in a total thickness of 0.180mm. Built to endure the most rigorous conditions, it boasts an impressive tensile strength of ≥300 N/25mm and a dielectric withstand voltage of 4 KV. Designed specifically for extreme heat operations, GL20S effortlessly withstands continuous exposure to 260°C for up to 30 minutes while guaranteeing a clean, residue-free removal. It is the ultimate solution for heavy-duty bundling, high-temperature masking, and critical electrical insulation.
| Item NO | Colour |
Colour (mm) |
Max Width (mm) |
Max Length (M) |
MOQ (m²) |
180° Peel Adhesion (N / 25mm) |
|---|---|---|---|---|---|---|
| GL20S | White | 0.180±0.010 | 500 | 500~2000M ( can be customized) | 2000 | 7↑ |
| Backing Material | Glass Fiber Cloth |
|---|---|
| Backing Thickness (mm) | 0.130 |
| Type of adhesive | Silicone Adhesive |
| Holding power (h) | 12↑ |
| Elongation at break (%) | 5↑ |
| Tensile strength(N/25mm) | 300↑ |
| Temperature resistance (℃/30mins) | 260 |
| Voltage resistance (kV) | 4 |
| Loop Tack Strength (N) | 2 |
Comes off clean
Easy to remove
Excellent high temperature resistance
Our products comply with RoHS standards. Test reports are available upon request.
Store at room temperature, away from light. The temperature should be 15-28℃, and the humidity should be 40%-70%.
The selection of this white glass cloth silicone tape should be carefully matched to your actual processing conditions, including peak soldering or operating temperatures, processing time, specific substrate materials, and required electrical insulation performance. To achieve optimal performance, ensure the application surface is clean, dry, and free of oil or dust, and apply adequate pressure using rollers or press equipment. For an accurate model recommendation, please consult our sales engineers.
